LSA / ZL1 Electric Water Pump Manifold

SKU:
Sale price

From $850.00

Regular price $875.00
Finish
Manifold Adapter
Motor Plate

Call for availability - Built to Order

LSA / ZL1 Electric Water Pump Manifold allows you to use a remote electric water pump and remote thermostat while using the LSA / ZL1 Supercharger with our LSA Race Drive or Gilmer Drive. Perfect for your maximum effort Drag Car, Slat Flat car, or Boat

Uses two -16AN ORB Fittings for the inlet/outlet, three piece design, compatible with the LSA Race Drive, LSA Gilmer Drive, LSA Flex Drive (Shaft Drive) & (Direct Drive)  and the Factory GM LSA Idler/DSX tuning Triple Idler

Includes two -16AN ORB Fittings

NOT INCLUDED : SUPERCHARGER DRIVE, PULLEYS, SUPERCHARGER, REMOTE ELECTRIC WATER PUMP

NOTE: There are no provisions for mounting a 6 rib tensioner for accessories (Alternator, Power Steering) This is designed to used in a dragster/race car/boat with no accessories or rigid tension accessories without a tensioner mounted to the water pump.

* Clears Jesel belt Drive when running a 1/4 motor plate

Need a compatible self tensioning Alternator mount?

Motion Raceworks Low mount Passenger Side Alternator mount (Not Compatible with our Flex Drive Kits with the low mount Tensioner) - Click here


NO RETURNS ON CUSTOM-BUILT PARTS

Installation:

The lower port is fluid in from the Radiator/Remote Electric Water Pump, upper port is fluid out

Need to run a motor plate? (Click Here
